358 prison fence specifications:
Height: 1.8m 2m 2.4m 2.7m 3.0m 4.0m 5.2m
Mesh aperture: 76.2x12.7mm
Horizontal wire: 4mm 12.5mm aperture
Vertical wire: 4mm 76.2mm centres
Post centres: 2m 2.2m 2.5m 3m
The panel are overlapped on each post and secured using clamp bars and M8 diameter bolts
Tensile strength: 540-690N/m2
Weld strength: 75% of the min tensile strength of the wire
Hot dipped galvanized powder coated color high security 358 wire mesh fencing for prison
