Product Description

Acoustic Insulation Wall Fence Acrylic Aluminum Noise Barrier Panel Prices Highway Sound Barrier supplier

Product Application

Acoustic Insulation Wall Fence Acrylic Aluminum Noise Barrier Panel Prices Highway Sound Barrier manufacture

Noise pollution

In our times, noise is high among those pollution sources that most impair our quality of life. Ever more traffic, engendered by continually developing mobility, further aggravates the nuisance. Measures to shield us from such environmental burdens are thus
assuming increasing and crucial importance.

Acoustic Insulation Wall Fence Acrylic Aluminum Noise Barrier Panel Prices Highway Sound Barrier details

JINBIAO Noise Barrier / Sound Barrier Fence

JINBIAO noise barrier for traffic and residential are made of aluminum or galvanized metal and fulfill eco-friendly natural plant fiber. The panels range from one-sided or double-sided highly absorbing quality and are also available in transparent design. The high quality and UV-resistant powder coating gives an appealing appearance to the JINBIAO sound barrier for traffic and residential.

METAL SHEET
PANEL HEIGHT	PANEL LEHGTH	SHEET THICKNESS	SHEET THICKNESS	PANEL TYPE
0.5m	2.0m	80mm	1.0-1.5mm	shutter or perforated
1.0m	2.5m	100mm
	3.0m
	4.0m
PC/PMMA SHEET
PANEL HEIGHT			HEIGHT	SHEET THINCKNESS	LIGHT TRANSMITTANCE
0.5m			2.0m	80mm	≥80%
1.0m			2.5m	100mm
1.5m			3.0m
			4.0m
SOUND BARRIER
TOTAL HEIGHT			LENGTH	RW	NRC
3.0m as standard			2.0m	≥30dB	≥0.84
						2.5m
						3.0m
						4.0m

Products Description

Metal panel

Metal type: galvanized sheet, aluminum sheet.
Appearance: perforated type, louver type.

Panel size: 1960~3960 mm length

500~1000 mm height

80~120mm thickness.

Other size can be customized according to your requirement.

Color: RAL colours

Acrylic / Polycarbonate panel

Thickness: 6~20mm

Density: 1.2g/m³

Light transmittance: over 90% for transparent color

Color: clear, bronze, green, blue, opal etc.

Safety: 10times stronger than normal glass and twice as tempered glass, almost no risk of breaking.

Life time: over 10years.

H-column

Size: 100 x 100 x 6 x 8 mm; 125 x 125 x 6.5 x 9 mm; 150 x 150 x 7 x 10 mm; 175 x 175 x 7.5 x 11 mm.

Finish: hot dipped galvanized & powder coated

Acoustic Insulation Wall Fence Acrylic Aluminum Noise Barrier Panel Prices Highway Sound Barrier factory

Weld details

Beautiful and continuous welding without leakage

Product Paramenters

JINBIAO Noise Reduction Coefficient

0.97 Tested by TUV

JINBIAO Sound Transmission Class

37dB test by TUV

Our Advantages

* Highly absorptive noise barrier system
* Easy installation or maintenance replacement
* Can be incorporated with other materials
* Can be easily relocated

* Minimum repair required only damaged panels to be replaced

* Fits standard support post systems
* Standard/custom modular sizes
* Manufacturing is consistent
* Custom panel sizes and shapes
* Choice of colours
* Framed clear or coloured acrylic
* Pre-printed graphics
* Using security cables on bridges and slopes are at lower risk
* Fire resistant
* Maintenance free
* Low life cycle costs
* Factory applied Anti-graffiti coating

Production And Quality Inspection

4 inspection procedures:

raw material inspection → Inspection during production → Trial assemble in factory → Inspection of loading

Trial assemble in our factory before loading

Packing and Shipping

Packing details

1. rubber mat at the bottom of the pallet to avoid the pallet destroyed the panel.

2. metal corners to keep the pallet more strong and wood plate on the panel pallet.

3. the metal plate under the plastic bandage to a pressure for fence panel.

4.according your request

Project case

Why Choose Us

Hebei Jinbiao Construction Materials Tech Corp.,Ltd was established in 1986 as manufacturing wire mesh fence and noise barrier in Anping County,Hebei Province,China.Our factory covers an area of 133200 square meters,with about 400 employees and more than 60 technicians.The registered capital of our company is 110 million,26 December 2014,the company was listed on the stock equity,becoming the first locally listed company in the area.

Product Quality: JINBIAO products have passed ISO9001 certificate of quality management system, occupational health and safety management system certificate, environmental management system certificate. Besides, JINBIAO has also set up a special quality inspection team to ensure that all products are well-qualified.
Product Market: JINBIAO products sell well both at home and abroad with outstanding quality and favorable price. Such as Russia,Singapore, Dubai, the United States, Canada, Australia, Japan etc.JINBIAO has won good appraise by oversea clients, enjoying a high reputation in industry.
